We Provide Intergrated Solutions For Block Making.
 |
 |
 |
 |
 |
 |
86
NP QT12-15C BRICK MACHINE FEATURES
1. The frame is evevated and widened design, large vibration force and pressure value, can produce kinds of curb stones, large retaining block, U-shape trench, slope protection bricks, railway slope protection bricks, vehicle road bricks, port road bricks, counterweight blocks etc.;
2. The machine body is made of super strong materials, meanwhile adopting a four-bar guiding method and longer wear-resistant sleeves, to ensure the balance of mold detachment and precise operation of the pressure head;
3. The aggregate materials trolly is controlled by two motors, control cylinders with curved arm propulsion +360° rotating distribution form, high speed, strong density;
4. The molds, pins are heat treated with quenching, tempering, carburizaton and nitriding, its service life far exceeds the national standard.
|
Equipment parameters |
|
|
Host Machine Powel |
51.5 kW |
|
Host Machine Weight |
11 tons |
|
Dimension |
5350*2280×3030mm |
|
Pallet Size |
1280×880*(25-45)mm |
|
Molding Cyclel |
15-20 sec/time |
|
Excitating Force |
128kN |
|
Production Capacity |
41.04 million pcs/year(240×115×53mm) |
|
Operation Standard |
JC/T2094-2021 |
| Paving Stone Series |
 |
| Hollow Block Series |
 |
Professional production of unburned brick machine
 |
 |
 |
| Bread brick | Holland brick | Pavement bricks |
Cement brick is a kind of new wall material, made of fly ash, coal slaggangue,tailings slag, chemicalslag or natural sand, seashoremud,etc.(one or several ofthe above raw materials) as main raw materials, cement as solidifying agent, without calcinationat high temperature.
|
About us
|
|
|
Langfang Nianpeng Machinery Equipment Processing Co., Ltd., committed to the concrete products equipment industry for 25 years, now has Langfang Hebei, Xiangtan Hunan, Cangzhou Hebei, the three major production bases and Nianpeng Interational Trade Co., Ltd., covers a total area of more than 60,000 square meters, more than 200 employees, the company has a mechanical design and development center, parts processing workshop, welding assembly workshop, mold heat treatment workshop, fully realized the independent researching and production of equipment, development, manufacturing,marketing domestic and international. Our company is a manufacturer specialized in the development and promotion of all kinds of slope protection bricks, large retaining blocks, U-shaped water trenches, sand-based permeable bricks, magic ground tiles, PC imitation stone bricks, curbstones, colored bricks, split bricks, standard bricks, hollow bricks, porous bricks, and other concrete products primary molding equipment. We always adhere to the implementation of the enterprise tenet of "professional achievement quality", and always adhere to the business philosophy of "lovalty, dedication, integrity, initiative" and "common growth with customers". In order to service our customers domestic and overseas better and faster , we also has established more than 20 offices nationwide. While continuously meeting the needs of the domestic market, the equipment is also exported to Russia, Mongolia. Kazakhstan, Pakistan, lran, Kuwait, Angola, Guinea, Ghana, Uganda, Kenva, Lesotho, SouthAfrica, Vietnam, Myanmar, Indonesia, Cambodia, Kyrgyzstan, India and other more than 40 "Belt and Road" countries, and has established long-term friendly cooperative relations with customers, our products and services are widely recognized by customers domestic and overseas.
|
|
|
|
|
Keyword: NP QT12-15C Block Making Machine
